DEEP WELL PUMP

Application
For pumping clean water with sand content less than 150g/m³
For well pumping, river pumping, farm irrigation, water supply,mining, draiaage in breeding industry.

Operating conditions
Water temperature up to 35?
Ambient temperature permissible up to 40?
4SDM Minimum internal diameter of well: 4"(100mm)
Maximum sand content: 0.25%
Maximum immersion depth: 80m

Motor
Rewindable motor
Insulation Class B
Protection IP68
NEMA dimension standards

Options on request
Special mechanical seal
Single phase motor with built-in capacitor
Single phase motor with control box
The length of cable: 2 Meter
Outlet dimension : 1¼"?1½"?2"
